Mark
Yato
Symbol
YT-99730
Series
GRF
Dimensions
360x190x320mm
Application
for heating public spaces
Nozzle diameter
0.86mm
Mass
2.9kg
Tension
220-240 V a.c.
Hose length
1.5 m
Cable length
1.2 m
Level of security
IPX4
Frequency
50 Hz
Electrical insulation class
AND
Overheating protection
95˚C
Air flow
320 m³/h
Engine power
25 W
Type of feed gas
G30/G31
Piezo ignition
Yes
Thermal power
15 kW
Feed gas pressure
70 MPa
Gas appliance category
I3B/P / I3P
Type of gas appliance
A3
Fuel consumption
1.09 kg/h
Portable gas heater in a metal casing. It is used for heating public utility rooms - workshops, halls and for drying during renovation and construction works. The casing is powder-coated, which protects the heater against rust. The heater has double protection against overheating. The device cuts off the fuel supply when the flame disappears or when the temperature exceeds 95 ℃.
thermal power: 15 kW
feed gas: propane-butane G30 / G31
air flow: 320 m³/h
fuel consumption: 1.09 kg/h
air pressure: 0.7 bar
weight: 2.9 kg
protection level: IPX4
motor power: 25W
ignition: piezo
insulation level: class I
gas device category: I3B/P/I3P
gas device type: A3
connection diameter: Φ 0.86 mm
dimensions: 360x190x320 mm
cable length: 1.2 m
voltage: 220-240V/50Hz
The set includes a pressure reducer and a 1.5 m hose
